Solar Cable Plica SOL 6 mm2

Discover the Plica Sol solar cable 6 mm2 - Your key to efficient energy transmission.
Secure your solar installations with the double-insulated Plica Sol solar cable 6 mm2, ideal for optimal energy transmission. With a length of 500 m and a voltage resistance of up to 1500 V, this high-quality solar cable offers maximum safety and efficiency for your solar projects. Perfectly suited for use in photovoltaic systems, the Plica Sol solar cable ensures lasting performance and resilience under all conditions. Invest in reliability and maximize your energy generation.
Meets standards: H1Z2Z2-K | EN 50618:2014

Conductor material

Copper

Conductor surface

Tinned

Conductor category

Class 5 = flexible

Number of strands per conductor

Conductor resistance at 20 °C

3.39 Ohm/km

Material core insulation

Polyolefin

Specification core insulation

Other

Core identification according to HD 308 S2

Core identification

Other

With protective conductor

Drain wire

Suspension element

Other

Material outer sheath

Polyolefin

Specification material outer sheath

Other

Screen

Cable geometry

Round

Protective barrier

Other

Flame retardant according to IEC 60332-1-2

Yes

Low smoke according to EN IEC 61034-2

Yes

Oil resistant according to EN IEC 60811-404

Yes

Low temperature resistant according to EN 60811-504+505+506

Yes

Nominal voltage U0

1500 V

Nominal voltage U

1500 V

Shape of conductor

Round

Max. conductor temperature

120 °C

Weight

73 kg/km

Solar Cable Plica SOL 6 mm2
