GES25 Insulation Hose in Silicone and Glass Fiber – Heat Resistant and Flexible
The GES25 insulation hose blends silicone rubber with a glass fiber braid, providing excellent flexibility and mechanical strength. These characteristics have proven reliable over the years in machinery and equipment manufacturing. The hose is highly chemically resistant, withstands temperatures from -40 to +235°C, and is self-extinguishing. It is also UV resistant and halogen-free, making it an ideal choice for demanding industrial applications where safety and durability are crucial.
Heat-resistant
Yes
temperature range
-40...+235
Fire behavior
self-extinguishing
UV-resistant
Yes
halogen free
Yes
strain rate
01:02
material
Silicone rubber / Fibreglass braid
19 Artikel
Reset filters
Filter
Item
Inner diameter mm
Wall thickness mm
Colour
Ø outside mm
Availability
SU
Price / SU in CHFexcl. VAT
- Item 610100200Inner diameter
mm 0.5Wall thickness
mm 0.2Colour RedØ outside mmAvailabilitySU 400 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100210Inner diameter
mm 1Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 400 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100220Inner diameter
mm 1.5Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100230Inner diameter
mm 10Wall thickness
mm 0.45Colour RedØ outside mmAvailabilitySU 100 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100240Inner diameter
mm 12Wall thickness
mm 0.45Colour RedØ outside mmAvailabilitySU 100 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100250Inner diameter
mm 14Wall thickness
mm 0.6Colour RedØ outside mmAvailabilitySU 50 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100260Inner diameter
mm 16Wall thickness
mm 0.6Colour RedØ outside mmAvailabilitySU 50 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100270Inner diameter
mm 18Wall thickness
mm 0.6Colour RedØ outside mmAvailabilitySU 50 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100280Inner diameter
mm 2Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100290Inner diameter
mm 2.5Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100300Inner diameter
mm 20Wall thickness
mm 0.9Colour RedØ outside mmAvailabilitySU 50 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100310Inner diameter
mm 22Wall thickness
mm 0.9Colour RedØ outside mmAvailabilitySU 25 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100320Inner diameter
mm 25Wall thickness
mm 0.9Colour RedØ outside mmAvailabilitySU 25 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100330Inner diameter
mm 3Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100340Inner diameter
mm 3.5Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100350Inner diameter
mm 4Wall thickness
mm 0.3Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100360Inner diameter
mm 5Wall thickness
mm 0.4Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100370Inner diameter
mm 6Wall thickness
mm 0.4Colour RedØ outside mmAvailabilitySU 200 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart - Item 610100380Inner diameter
mm 8Wall thickness
mm 0.45Colour RedØ outside mmAvailabilitySU 100 mPrice / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart
